      Vent-A-Hood® Designer Series 36" Black Carbide Wall Mounted Range Hood


      Model #:

      JPH236/C2 BC

      Model #: JPH236/C2 BC
      1478406
      Vent-A-Hood
      $4,082.00

      At a Glance

      Product Dimensions 30"h x 36"w x 24"d

      Make a strong statement in your kitchen with an elegant Vent-A-Hood® wall-mounted Designer Series range hood. The JDH/C2 range hood is concave with offset lip styling and is equipped with LED lighting.Read More

      $4,082.00

      View Delivery & Pickup OptionsAdd Zip Code

      What We Offer

      Protect Your Purchase

      View Options

      5 year Parts & Labor Warranty $3000 -$4999

      $499.99

      Services

      View Options

      None Selected

      Protect Your Purchase5 Yr $499.99 | 3 Yr $299.99

      Get to know this product.

      Product Overview

      Product Overview

      Quiet

      Turn on a Vent-A-Hood® and you’ll hear only a whisper of air movement, because the Magic Lung® system provides the quietest ventilation available. Vent-A-Hood®s with LED lights also feature SensaSource® . SensaSource® raises the blower speed from low to high based on temperature for optimal grease control, fire safety, and even quieter operation.

      How quiet is a Vent-A-Hood®? The test results shown below were generated at a certified independent industry testing lab. All tests were measured at full speed to demonstrate the most accurate sound rating (other manufacturers may use lower speeds for testing which don't reflect accurate operating sound levels).

      Vent-A-Hood's® Magic Lung® "multi-blower technology" allows CFM to double, triple, or quadruple with very little effect on sound levels.

      Efficient

      The powerful Magic Lung® blower traps all cooking contaminants, liquefies grease vapor and removes heat-polluted air. Because the Magic Lung® blower combines sufficient air pressure and constant speed with centrifugal filtration—and because it doesn’t pull air through a filter—it is the most efficient kitchen ventilation available today.

      Easy-Cleaning

      The Magic Lung® housing snaps apart for easy cleaning in the dishwasher or with warm, soapy water. Moreover, the Magic Lung® is the only ventilation system that collects the grease in the easily cleaned housing rather than in hard-to-reach areas behind a mesh or baffle filter.

      Fire-safe

      The Magic Lung® is the only residential ventilation system on the market today that prevents fire from spreading to the rest of the home. Constant speed creates centrifugal pressure that prevents fire from entering the ductwork. As needed, SensaSource® increases blower speed to its normal level to maintain this safety feature.

      Powerful

      Magic Lung® blowers can be configured to provide the power you need for even the most demanding cooking surface. Each highly efficient Magic Lung® blower supplies 300 CFM of air movement; you can combine multiple blowers in a single Vent-A-Hood® to create the perfect ventilation for your cooking surface.

      All Vent-A-Hood Magic Lung products are suitable for use in damp locations (outdoor applications such as a covered patio) when installed in a GFCI protected branch circuit.

      Useful Documents
      Specifications

      General Specs

      Width (in.)36
      Height (in.)30
      Duct Size (in.)8" Round
      Depth (in.)24
      CollectionDesigner Series
      ColorBlack
      Color Finish NameBlack Carbide
      Range Hood TypeWall Mounted
      Outdoor ApprovedYes
      Appliance Fit Width (in.)36
      Maximum CFM600
      Bulb TypeLED
      Sones Rating6.5
      Vent LocationTop
      Height Above Cooktop30
      Height Above Cooktop Centimeter76.20
      Voltage115
      Amp4
      Frequency60
      Range Hood FeaturesApproved For Outdoors, Light
      Noise Level (Sones)Standard - (High)
      Ventilation TypeDucted

      WarningProposition 65 Warning for California Residents
